Custom‑made 3 head nozzle compatible with Panasonic NPM pick‑and‑place machine. Designed for special irregular components, stable multi‑point vacuum suction, high placement accuracy for non‑standard SMT parts.
| Part Name | Pansonic Custom Nozzle |
|---|---|
| Application | Panasonic CM602, NPM-W,NPM-W2,NPM-D3 12H/16H Mounter |
Panasonic Custom 3‑Head Nozzle is specially developed for Panasonic NPM series pick‑and‑place machines, dedicated to picking and placing special irregular‑shaped components in SMT production. It is suitable for the following applications:
1. Special multi‑pin and irregular packaged components that standard nozzles cannot handle.
2. Tape‑packaged special hardware and connector parts as shown in the picture.
3. Custom‑size non‑standard components requiring multi‑point balanced vacuum suction, ensuring stable holding and precise placement.
This custom‑built nozzle adopts multi‑hole suction structure to realize multi‑point adsorption. It is processed with high‑hardness anti‑static material, effectively prevents component slipping and dropping during high‑speed production. Strict dimension inspection is carried out before delivery to ensure good compatibility with Panasonic NPM equipment. Custom modification according to customer component samples is supported.
