This KIC2000 profilers in the electronic manufacturing industry are widely used, especially in SMT production lines. They can measure the temperature of various areas in the SMT furnace, provide the furnace temperature curve, control the entire process of PCB baking, and ensure that the PCB baking is complete and stable. Thereby improving SMT quality.
| Accuracy | +/-1.2℃ |
|---|---|
| Resolution | 0.3 ℃ ～ 0.1 ℃ |
| Internal operating temperature: | 0 ℃ ～105 ℃ |
| Measuring temperature range: | 150 ℃ ～1050 ℃ |
| Deimension | L320 * W86 * H26 CM |
KIC oven reflow temperature tester, KIC 2000/KIC START/KIC EXPLORER oven temperature tester is used to test temperature curves and can be used in solder paste reflow soldering, glue curing, wave soldering, rework stations, and other processes.
Feature:
1. Automatic thermocouple position setting import.
2. Automation of temperature curve evaluation.
3. Automatic visual operation instructions.
4. When the instrument is overheated or the battery power is too low, it will automatically give instructions and stop the temperature curve test.
5. Automatic retrieval can ensure the integrity of temperature curve data.
6. The stability of the production process is automatically confirmed.
|
Accuracy:
|
+/-1.2℃
|
|
Resolution:
|
0.3 ℃ ～ 0.1 ℃
|
|
Internal operating temperature:
|
0 ℃ ～105 ℃
|
|
Applicable thermocouples:
|
9/12 K type thermocouples
|
|
Measuring temperature range:
|
150 ℃ ～1050 ℃
|
|
System compatibility:
|
compatible with all PCs
|
|
Power requirements:
|
9v alkaline batter
|
|
Dimension(with standard insulation cover):
|
L320*W86*H26 CM
|
