9498 396 02670 Yamaha 312A SMT nozzle assembly, part number KHY-M7720-A0, cross-references KHY-M7720-A1 and KHY-M7720-A0X. Equipped with dual tip sizes 1.2×0.45mm / 0.6×0.3mm, engineered for Yamaha YS and YG series mounters, delivers flexible component pickup for varied small chips in PCB assembly.
| Part Name | Yamaha 312A Nozzle |
|---|---|
| Part Number | 9498 396 02670, KHY-M7720-A0 |
| Model | 312A |
| Machine Model | Yamaha YS12 YS24 YS100 YG12 YG200 YSM20 Machine |
This Yamaha 312A nozzle assembly (KHY-M7720-A0, 9498 396 02670) is a high-precision SMT spare part designed for surface mount pick-and-place operations.
It comes with dual specification nozzle tips: 1.2 × 0.45 mm and 0.6 × 0.3 mm, allowing manufacturers to handle multiple miniature electronic components without frequent nozzle swapping.
Compatible with Yamaha YS series YS12, YS24, YS100 and YG series YG12, YG300 placement machines. Strict machining tolerance ensures stable vacuum holding and accurate component alignment during high-speed production cycles.
This assembly can replace part numbers KHY-M7720-A1 and KHY-M7720-A0X. It is a reliable replacement spare to reduce pick failures and improve production throughput for SMT PCB workshops. We support bulk inquiry and fast global shipment.
Type 301A Nozzle 0603~1005 Component( Standard Nozzle)
Type 302A Nozzle 1608~3216 Component (Standard Nozzle)
Type 311A Nozzle 0603 Nozzle Component
Type 312A Nozzle 1005~1608 Component
Type 313A Nozzle 2012~3225 Component
Type 3010A/3110A Nozzle 0402 Component(Special)
Type 303A/314A Nozzle 4532~7343 Component SOP
Type 304A/315A Nozzle QFP etc.
Type 306A/317A Nozzle MELF
Type 307A/318A Nozzle 32mmx32mm~45mmx45mm etc. (for HM head (NO3, NO8; HM5 head(NO 2)
